Key Features- High accuracy: The device offers 1% distance accuracy and resolution, allowing for precise fault location.
- Long range: It has a maximum range of 6 km (19,000 ft) and a minimum range of 7 m (23 ft).
- Dead zone: The T1660 has a short dead zone of just 0.5 meters, ensuring it can detect faults close to the testing point.
- Adjustable settings: Users can adjust the Velocity of Propagation (VoP) from 1% to 99% and select an output impedance of 25, 50, 75, or 100 ohms to match the specific cable being tested.
- Easy to use: With just six control buttons and a simple menu system, the T1660 is designed for user-friendliness.
- High-quality display: The device features a large, 3.5-inch, 328 x 256 pixel backlit color LCD that provides a clear view of the test results.
- Battery life: The T1660 typically provides up to 12 hours of continuous operation on six AA alkaline or NiMH rechargeable batteries.
- Durability: The unit is rated IP54 for protection against dust and water ingress, ensuring reliability in the field.
- Safety features: An optional Mains Blocking Filter module allows for safe testing on live 3-phase mains cables.
|
