Key Features- IEC 61000-4-30 Class A compliance: The analyzer meets the highest industry standard for power quality measurements, ensuring reliable and accurate data.
- Intuitive interface: It features a large, 7-inch color LCD touch screen with multilingual online help for easy navigation and use.
- Real-time monitoring: The device can monitor electrical networks and provides real-time alarm notifications, including the ability to send alerts via email.
- Voltage (up to 1,000 V AC and 1,200 V DC).
- Current (compatible with multiple clamp-on sensors).
- Power (Active, Reactive, and Apparent).
- Power factor, harmonics (up to the 63rd order), and interharmonics.
- Flicker, unbalance, and transients (down to 2.5 µs).
- Inrush current with a pre-trigger function for accurate waveform capture.
|
