Kyoritsu 3005A Digital Insulation/Continuity Tester, 600V

Description

The Kyoritsu KEW 3005A is a digital insulation and continuity tester for measuring insulation resistance and checking the continuity of electrical circuits. Its key features include multiple test voltages, safety warnings, and an auto-null function for enhanced accuracy.

Key Features

• Insulation resistance testing: Tests insulation resistance with selectable voltages of 250V, 500V, and 1000V.
• Bargraph display: Provides a visual representation of the insulation resistance alongside the digital value.
• Continuity testing: Measures continuity with a 200mA testing current, conforming to IEC 61557 standards.
• Auto-null function: Automatically subtracts the test lead resistance from continuity measurements for more accurate readings.
• Live circuit warning: A beeper and a flashing symbol warn the user if an external AC voltage is present.
• Automatic discharge: The device automatically discharges any residual charge in the circuit under test after an insulation test is completed.
• Auto-power-off: Extends battery life by automatically shutting off after about 10 minutes of inactivity.
• Safety compliance: Meets IEC 61010-1 CAT III 300V safety standards.
• IP54 rating: Provides protection against dust and splashing water.
