Key Features- Fast measurement speed: The tester can measure insulation resistance in as little as 0.5 seconds.
- Multiple test voltages: Offers six selectable test voltages: 50V, 100V, 125V, 250V, 500V, and 1000V, making it a versatile tool for different applications.
- Data memory function: Equipped with internal memory to save, recall, and delete up to 1,000 sets of measurement data.
- USB interface: Measured data can be transferred to a PC via an optional USB adapter for further analysis and report generation.
- Backlit display: An illuminated LCD with an auto-sensing backlight facilitates working in dimly lit areas.
- Diagnostic testing: Supports Polarization Index (PI) and Dielectric Absorption Ratio (DAR) diagnostic insulation tests.
- Continuity testing: Features a continuity test function with a "Zero \(\Omega \) adjustment" to compensate for test lead resistance, ensuring accurate low-resistance measurements.
- Compact and durable design: Built to be portable and robust for use in the field.
- Auto AC/DC voltage detection: For voltages above 30V, the device automatically detects if the input is AC or DC.
|
