Key Features- Electrical installation and maintenance: Testing the insulation integrity of wiring, cables, and electrical components.
- HVAC (heating, ventilation, and air conditioning): Technicians can use it to test insulation resistance and monitor temperature in HVAC systems.
- Industrial equipment evaluation: The combination of True RMS measurement and insulation testing makes it useful for evaluating industrial circuits and equipment.
- Automotive diagnostics: Used to check battery voltage, continuity, and perform insulation checks on a vehicle's electrical systems.
- Insulation Resistance Measurement (Megger): This is its primary special application. It can test insulation up to 2GΩ at five different selectable test voltages: 50V, 100V, 250V, 500V, and 1000V.
- DAR/PI Modes: It automatically calculates the Polarization Index (PI) and Dielectric Absorption Ratio (DAR), which are critical diagnostic tools for assessing the quality and condition of electrical insulation.
- Temperature measurement: With a K-type thermocouple, it can measure a wide temperature range, from -30°C to 1300°C (-22°F to 2372°F).
- True RMS: The True Root Mean Square feature allows for accurate measurement of AC voltage and current, even on non-linear or distorted waveforms.
|
