Key Features- Multifunctional measurement: Measures AC/DC voltage (up to 600V), AC/DC current (up to 200mA), and resistance (up to 20 MΩ).
- Auto and manual ranging: Provides flexible measurement options, allowing the meter to automatically select the correct range or giving the user control over the measurement scale.
- Logic level test: A special function for testing digital signals, with LED indicators (red for high, green for low) and an input impedance of 1 MΩ.
- Non-Contact Voltage (NCV) detection: Safely detects the presence of AC voltage (over 50V) without physical contact, indicated by sound and a flashing LED.
- Max value hold: Records and displays the maximum value measured.
- Data hold: Freezes the current reading on the display for easier analysis.
- Additional features: Includes a continuity buzzer that sounds at under 50Ω, a diode test, an auto power-off function, and a low battery display.
- Durable construction: Features double molding for enhanced durability and protection.
- Safety rating: Certified with a CAT III 600V safety rating.
|
