Key features
- High current capacity: The unit can deliver up to 300A DC test current.
- Ultracapacitor technology: An internal ultracapacitor provides instantaneous high-current output, allowing for multiple tests in rapid succession without needing to recharge.
- Auto-ranging: It automatically selects the correct range from 0.1 µΩ to 3000 mΩ for accurate measurements.
- Portability: It is lightweight (1.15 kg) and battery-powered, making it ideal for fieldwork.
- Durability: The MOM3 has a rugged rubber body and an IP54 rating for protection against drops and harsh environments.
- Data storage: It can store over 2,000 test values, which can be transferred via USB-C to a PC.
- 5-meter Kelvin clamps: The BK-30381 kit includes two Kelvin clamps, one with a 1.3-meter red cable and another with a 5-meter black cable.
- Applications: Common uses include measuring contact resistance in circuit breakers, busbar joints, and other high-current connections.
|
