Key features
- High Accuracy: Provides accurate resistance measurements within 3 seconds, with a basic accuracy of 0.2%.
- Automatic Operation: Automatically selects the most suitable test current, up to 10 A DC, to measure resistance from 0.1 µΩ to 2000 Ω.
- User Control: Features a menu system and two-axis paddle for manually selecting the test current, giving you more control than the standard DLRO-10 model.
- Data Logging and Storage: Includes on-board memory to store up to 700 test results along with alphanumeric notes entered via a keypad. An RS232 port allows for data download to a PC.
- Backlit LCD Display: A large, backlit LCD display is easy to read in all lighting conditions.
- Automatic Current Reversal: Cancels out the effects of standing voltages (EMFs) by taking both forward and reverse measurements and averaging them.
- Safety Features: Includes high voltage warnings, continuity detection for test leads, and protection against accidental connection to external voltages up to 600 V.
- Operating Modes: Offers multiple testing modes, including Normal, Auto, Continuous, Inductive, and a Unidirectional mode for faster measurements.
- Versatile Power Supply: Can be powered by a rechargeable NiMH battery pack or an optional mains power supply.
- Rugged and Portable: Built into a strong, lightweight case with an IP54 rating during operation, making it suitable for demanding environments.
|
