Key features
- Automatic operation: The DLRO10 can automatically select the most suitable test current, up to 10A, and provides accurate results in under three seconds.
- Auto current reversal: This feature automatically reverses the test current and averages the results to cancel out any standing EMF effects, ensuring a more accurate measurement.
- Multiple operating modes: The instrument offers various testing modes, including manual, auto, continuous, and inductive modes for testing different types of components.
- Safety features: It includes visible warnings for high voltages and current flow. It is also protected up to 600V without blowing a fuse.
- Portable and durable: The DLRO10 is built into a strong, lightweight case, making it suitable for both field and laboratory use. Some models, like the DLRO10HD, feature a heavy-duty case with an IP65 rating for use in harsh weather.
- Four-terminal measurement: This method uses separate leads for current and voltage measurements to eliminate the resistance of the test leads, providing a more precise reading of the resistance being tested.
- Rechargeable battery: It is powered by a rechargeable battery, with the option for mains power on some models, allowing for continuous testing.
|
