Key features- Test voltages: 250V, 500V, and 1000V DC for insulation testing.
- Insulation resistance range: 10 kΩ to 999 MΩ.
- Continuity testing: Measures continuity up to 100Ω, with an adjustable buzzer for quick testing.
- Resistance measurement: Features a resistance range from 10Ω to 1 MΩ.
- Voltage measurement: Capable of measuring up to 600V AC or DC.
- Data storage: Can save over 1,000 test results to its internal, non-volatile memory.
- PC downloading: A USB interface allows you to download stored data to a computer for analysis and report generation.
- Dual display: Combines a large digital display for clear readings with an analog arc for the "feel" of a traditional needle meter.
- Rugged construction: Built with a tough, rubber-armored, impact-resistant case and a protective display cover, making it suitable for field use.
- Safety features: Includes the "Intelligent Safety System" with a live voltage warning, safety lockout to inhibit testing on circuits over 50V, and an automatic discharge function after an insulation test.
- Additional features: A backlit display and range selection for low-light conditions, auto power-off, and a switched test probe for hands-free testing.
|
