Key features
- Insulation testing: Offers selectable test voltages of 50V, 100V, 250V, 500V, and 1000V, with a stabilized output voltage for improved accuracy. A variable test range allows for precise voltage selection from 10V to 1000V.
- Advanced diagnostic testing: Performs Polarization Index (PI) and Dielectric Absorption Ratio (DAR) tests, which are important for diagnosing insulation health.
- Continuity testing: Features a faster, single auto-ranging continuity function from 0.01 Ω to 1.0 MΩ, with both 20 mA and 200 mA test options.
- Voltage measurement: Includes True RMS voltage measurement for both AC and DC, up to 600V.
- Memory storage: The built-in memory can store over 1000 test results for later recall and analysis.
- Safety features: Includes live circuit detection and protection, and is rated for safety in CAT IV 600V and CAT III 1000V environments.
- Durable design: The instrument is sealed to IP54 for protection against dust and water ingress and has a rubber over-molding for shock absorption and grip.
|
