Key Features & Specifications
- Optical System: Utilizes a continuous zoom objective lens with a 6.3:1 zoom ratio (0.8X–5.0X) to maintain image plane parfocality.
- Magnification:
- Standard: 8X–50X with included 10X/22mm wide-field eyepieces.
- Expandable: Compatible with auxiliary objectives (0.5X and 2.0X) and optional eyepieces (15X, 20X, 25X, 30X) for specialized viewing.
- Viewing Head: A binocular or trinocular head inclined at 45° and rotatable 360°, with an adjustable interpupillary distance of 52–75mm.
- Working Distance: Standard working distance is 115mm, which can be extended to 211mm using a 0.5X auxiliary objective.
- Specialized Functions:
- Anti-static: The zoom tube and eyepieces are grounded to protect sensitive electronic samples during IT industry inspections.
- Sealing: Designed for high-humidity environments, protecting internal optics from oil and water vapor.
- Illumination: Typically equipped with both reflected (top) and transmitted (bottom) LED lighting.
